2026 Mercury 200HP PRO XS FOUR STROKE 25" SHAFT- 200XL

Listing image
Specifications

Model 200 PRO XS Category Name Outboard Engines Year 2026
Stock Number MER594695 Sale Type New Manufacturer Mercury
Name ProXS 200HP HP / KW 200 / 147 Starting Electric Start with SmartStart Protection
Steering Big Tiller (optional) Hydraulic (standard) Power (optional) Horsepower 200 Engine Type V8
Trim System Power trim and tilt Shaft Length 25" Shaft Length 20" / 508 mm 25" / 635 mm
Gearcase Ratio 1.75:1 (TorqueMaster or 5.44"); 1.85:1 (4.8") Displacement (L) 4.6L Recommended Fuel Unleaded Regular 87 Octane Minimum (R+M/2) or 90 RON 10% Ethanol Maximum
Full Throttle RPM 5600-6200 Alternator Amp / Watt 85-amp (1071 Watt) with Idle Charge Displacement (CID/CC) 279 CID
Smartcraft Compatible Cylinder Configuration V-8 [64 degree] with Dual Overhead Cam [DOHC] and 32-valves Dry Weight *Lightest Model Available 511 lbs / 232 kgs
Price 30,730 CAD Horsepower
Description

In Stock at Mobile Marine & Powersport in Huntsville, Ontario: 2026 Mercury 200HP PRO XS FOUR STROKE 25" SHAFT- 200XL

Experience top-tier performance with the 200HP. Available at Mobile Marine, your trusted Mercury repower specialists in Muskoka. Whether you are upgrading for more power, better fuel efficiency, or the latest digital technology, repowering your boat is a smart, cost-effective way to enjoy modern reliability without replacing your hull.

At Mobile Marine, you can choose to purchase your new outboard engine only, or have our certified technicians professionally install, rig, and lake test your setup to ensure it’s perfectly propped and performing at its best.

When you choose Mobile Marine, you’re backed by: Expert Service & Support, Competitive Financing Options and a Wide Selection of Accessories & Upgrades.

Visit us in Huntsville to see why boaters across Muskoka trust us for professional outboard repowers. Check out our Google reviews to hear from our satisfied customers!

Call us at 705-789-3932 or email sales@mobilemarine.com

Our team will respond as soon as possible to discuss your unique repower needs and get your boat powered with a new Mercury outboard.
FEATURES

TorqueMaster Gearcase

The lightweight TorqueMaster gearcase (featured on select V8 models) has a 1.75:1 gear ratio and a robust 1.25-inch-diameter prop shaft designed for semi-surfacing, high-speed applications.

Adaptive Speed Control

Adaptive Speed Control maintains a desired rpm regardless of changes in load or conditions without adjustments to the throttle lever position – a first for the outboard industry.

Performance-Tuned Exhaust

Exhaust tone has been fine-tuned to provide a brawny performance-inspired sound quality that’s unmistakable on the water yet quieter than competing high-output engines.

Transient Spark Technology

Transient Spark Technology electronically adjusts the ignition timing of the engine as needed. This subtle, automatic change produces additional torque for faster hole shot and acceleration.

Extra Charging Power

A powerful alternator provides net charging output of 20 amps at idle and 85 amps at wide open throttle. Idle Charge battery-management technology automatically increases idle rpm to boost alternator output and recharge low batteries.
SMARTCRAFT

SmartCraft. Boating with a Higher IQ.

SmartCraft® is a full suite of digital technologies, fully integrated and totally coordinated. Gauges, sensors, vessel systems, computer-controlled features - one total package, one high level of control. Make your boating experience easier, safer, and a lot more enjoyable. Get smart.

Joystick Pilotinghttps://samerwebapp01apncus01.azureedge.net/mmgw-env-b/filer_public/c9/be/c9bebc25-e03b-43f5-a6c8-adc859773ace/mercury_productimages_joystick_1000.png

300hp SeaPro AMS outboards are compatible with Joystick Piloting for Outboards. Joystick Piloting is designed and personalized for vessels powered by two to six SeaPro outboards. Mercury Joystick Piloting was the industry’s first joystick system for outboards and remains the best-selling marine joystick system.

VesselView Mobilehttps://samerwebapp01apncus01.azureedge.net/mmgw-env-b/filer_public/10/7e/107e3a2d-bcce-484b-8e4f-0585f3ef4577/mercury_productimages_vvm_1000.png

VesselView Mobile allows boaters to use a mobile device (smartphone or tablet) to connect with their Mercury outboard or sterndrive engine(s). The plug-and-play module connects via Bluetooth, providing quick, convenient access to your engine’s data.

VesselView Mobile is compatible with all SmartCraft-capable Mercury outboards (2004 and newer, 40hp and above).

Active Trimhttps://samerwebapp01apncus01.azureedge.net/mmgw-env-b/filer_public/ee/7f/ee7f2c7f-b740-4ef2-8a3b-4ddf0508d8ce/mercury_productimages_activetrim_1000.png

Active Trim makes boating easier and more enjoyable by automatically trimming outboard engines. Active Trim simplifies boat operation while improving engine performance and decreasing fuel costs.

Active Trim is compatible with all current SmartCraft-capable Mercury outboards (40hp and above).



VesselView Linkhttps://samerwebapp01apncus01.azureedge.net/mmgw-env-b/filer_public/0e/48/0e4833a3-1cfc-4311-9750-46cce41ad84b/mercury_productimages_vvlink_800.png

VesselView Link integrates an existing multi-function display with Mercury engine(s) to place information and control at the driver’s fingertips. Its user interface is easy to navigate, and it integrates chart-plotter, sonar, radar and more into one display.

VesselView Link is compatible with all SmartCraft-capable Mercury outboards (2004 and newer, 40hp and above).

DTS Hot Foothttps://samerwebapp01apncus01.azureedge.net/mmgw-env-b/filer_public/b6/15/b6151fc0-1e1e-4071-9240-562ec42269f2/mercury_productimages-dts-hotfoot_1000.png

A Digital Throttle & Shift (DTS) Hot Foot pedal allows you to keep both hands on the wheel during high-speed runs. DTS provides precise handling, seamlessly connects with compatible displays and delivers instant response and total control with no hesitation.
DTS Hot Foot pedal is compatible with 200 - 300hp Pro XS outboards.


PERFORMANCE

Unmatched Power and Speed

The V8 and V6 Pro XS outboards perform like no other, with a dual overhead cam design that delivers instantaneous throttle response and immediate power.

Superior Fuel Economy

Advanced Range Optimization improves cruise-speed fuel efficiency by automatically adjusting fuel delivery so seamlessly the operator won’t feel or hear it.

Lightweight Heavyweight

4.6L V8 and 3.4L V6 Pro XS outboards offer a combination of ample torque and less weight – ideal for heavier loaded boats.

Unmatched Power and Speed

The V8 and V6 Pro XS outboards perform like no other, with a dual overhead cam design that delivers instantaneous throttle response and immediate power.

Superior Fuel Economy

Advanced Range Optimization improves cruise-speed fuel efficiency by automatically adjusting fuel delivery so seamlessly the operator won’t feel or hear it.

Lightweight Heavyweight

4.6L V8 and 3.4L V6 Pro XS outboards offer a combination of ample torque and less weight – ideal for heavier loaded boats.


PRO XS ADVANTAGE

Ultimate Performance:

No outboard gets from zero to wide-open quicker than a Mercury Pro XS with 4.6L V8 and 3.4L V6 muscle. This is performance that will rocket your rig out of the hole and to the next hot spot in an instant.

Squeezing Speed from Fuel:

Mercury V8 and V6 Pro XS models transform every drop of fuel into performance to deliver excellent economy at cruising speed and wide-open throttle.

Tournament-Winning Torque:

More displacement delivers more torque and Transient Spark technology optimizes spark timing to boost that torque during hole shot.

Smart Charging:

A powerful alternator provides net charging output of 20 amps at idle and 85 amps at wide open throttle. Idle Charge battery-management technology automatically increases idle rpm to boost alternator output and recharge low batteries.
RESOURCES
Name Link
300hp Outboard Specifications Download
250hp Outboard Specifications Download
225hp Outboard Specifications Download
200hp Outboard Specifications Download
175hp Outboard Specifications Download
